Development Best Practices

All About Perspective

R is the standard-bearer for data analysis tooling

Shiny App Development

Not just providing another interface for data analysis

You are engineering an entire workflow

This Could Happen to You

Thinking of You

These principles can guide (future) you on the right path:

• Deliberate control of app dependencies
• Managing code complexity with native R frameworks
• Creating modules for streamlined organization and re-usability

Others not covered today

• Rapid prototyping in design process
• Defending against regressions with testing
• Version control for collaboration and peace of mind

Application Dependencies

It’s Never Just Shiny

… at least for production-quality apps!

• External data sources
• Connections to other execution backends
• Additional R packages!

Turned Upside-Down

Imagine your application is working great!

update.packages(ask = FALSE)
remotes::install_github("pkg")

Turned Upside-Down

ggplot2 version 0.9.3

ggplot2 version 1.0.0

Take Control with {renv}

Create reproducible environments for your R projects.

• Next generation of {packrat}
• Isolated package library from rest of your system
• Transfer projects to different collaborators / platforms
• Reproducible package installation
• Easily create new projects or convert existing projects with RStudio or built-in functions.

Under the Hood

Upon initializing a project:

1. Project-level .Rprofile to activate custom package library on startup
2. Lockfile renv.lock to describe state of project library
3. renv/library to hold private project library
4. renv/activate.R performs activation

Application Structure

Enter the {golem}

Opinionated framework for building production-grade Shiny applications as R packages

• Scripts guide you with first steps akin to {usethis} & {devtools}
• Encourages Shiny best practices (especially modules)
• Streamlines deployment on multiple platforms

What are Modules?

Building blocks to compose any Shiny app out of smaller, more understandable pieces

• Avoids namespace collisions when using same widget across different areas of your app
• Allow you to encapsulate distinct app interfaces
• Organize code into logical and easy-to-understand components
• Facilitate collaboration

Sound familiar?

• R functions also help avoid collisions in variable names with general R code
• Essential for creating non-trivial and extensive workflows

Anatomy of a Function (UI)

artUI <- function() {
  tagList(
    checkboxInput(
      "input1",
      "Check Here"
    ),
    selectInput(
      "input2",
      "Select Object",
      choices = c("jar", "vase"),
      selected = "jar",
      multiple = FALSE
    ),
    plotOutput("plot1")
  )
}

Anatomy of a Module (UI)

artUI <- function(id) {
  ns <- NS(id)
  tagList(
    checkboxInput(
      ns("input1"),
      "Check Here"
    ),
    selectInput(
      ns("input2"),
      "Select Object",
      choices = c("jar", "vase"),
      selected = "jar",
      multiple = FALSE
    ),
    plotOutput(ns("plot1"))
  )
}

Anatomy of a Module (UI)

artUI <- function(id) {
  ns <- NS(id)
  tagList(
    checkboxInput(
      ns("input1"),
      "Check Here"
    ),
    selectInput(
      ns("input2"),
      "Select Object",
      choices = c("jar", "vase"),
      selected = "jar",
      multiple = FALSE
    )
  )
}

• id: String to use for namespace
• ns <- NS(id): Create proper namespace function

Anatomy of a Module (Server)

artServer <- function(input, output, session) {
  df <- reactive({
    # do something fancy
  })

  output$plot1 <- renderPlot({
    ggplot(df(), aes(x = x, y = y)) +
      geom_point()
  })
}

Anatomy of a Module (Server)

artServer <- function(id) {
  moduleServer(
    id,
    function(input, output, session) {
      df <- reactive({
        # do something fancy
      })

      output$plot1 <- renderPlot({
        ggplot(df(), aes(x = x, y = y)) +
          geom_point()
      })
    }
  )
}

Minimal changes necessary

Anatomy of a Module (Server)

artServer <- function(id) {
  moduleServer(id,
    function(input, output, session) {
      df <- reactive({
        # do something fancy
      })

      output$plot1 <- renderPlot({
        ggplot(df(), aes(x = x, y = y)) +
          geom_point()
      })
    }
  )
}

:thinking: id

• `moduleServer(): Encapsulate server-side logic with namespace applied.

Invoking Modules

ui <- fluidPage(
  fluidRow(
    artUI("mod1")
  )
)

server <- function(input, output, session) {
  artServer("mod1")
}

shinyApp(ui, server)

Giving and Receiving

artUI <- function(id, choices = c("jar", "vase")) {
  ns <- NS(id)
  tagList(
    checkboxInput(
      ns("input1"),
      "Check Here"
    ),
    selectInput(
      ns("input2"),
      "Select Object",
      choices = choices,
      selected = choices[1],
      multiple = FALSE
    ),
    plotOutput(ns("plot1"))
  )
}

• Reasonable inputs: static values, vectors, flags
• Avoid reactive parameters
• Return value: tagList() of inputs, output placeholders, and other UI elements

Giving and Receiving

artServer <- function(id, df, title = "My Plot") {
  moduleServer(id,
    function(input, output, session) {
      user_selections <- reactive({
        list(input1 = input$input1, input2 = input$input2)
      })

      output$plot1 <- renderPlot({
        ggplot(df(), aes(x = x, y = y)) +
          geom_point() +
          ggtitle(title)
      })

      user_selections
    }
  )
}

• Input parameters (and return values) can be a mix of static and reactive objects

To () or not to ()

# app server
df <- reactive({
  art_data |>
    filter(dept == input$dept)
})

artServer("mod1", df)

artServer <- function(id, df, title = "Amazing") {
  moduleServer(id,
    function(input, output, session) {
      user_selections <- reactive({
        list(input1 = input$input1,
             input2 = input$input2)
      })

      output$plot1 <- renderPlot({
        ggplot(df(), aes(x = x, y = y)) +
          geom_point() +
          ggtitle(title)
      })

      user_selections
    }
  )
}

• Reactive parameters reference by name: df
• Inside module, invoke reactive parameter as you would any other reactive in Shiny: df()
• Any reactive(s) returned by module should also be reference by name: user_selections, user_selections()

Code-Along

Applying {golem} & {renv}to our simclindata.shiny application

engineering-shiny.org
