Design & User Experience

---

But … I’m not a Web Designer?

• Wealth of packages available in the Shiny ecosystem
• Plug-in favorite theme styles
• Ability to go as low-level as desired with CSS and JavaScript

💡 It’s not all about you! (That’s good)

Language of the Web

---

Shiny

dept_choices <- c("Ancient Near Easter Art", "American")
selectInput(
  "dept",
  "Select Department",
  choices = dept_choices
)

HTML

<div class="form-group shiny-input-container">
  <label class="control-label" id="dept-label" for="dept">
    Select Department
  </label>
  <div>
    <select id="dept" class="form-control">
      <option value="Ancient Near Easter Art" selected>Ancient Near Easter Art</option>
      <option value="American">American</option>
    </select>
  </div>
</div>

Multiple Levels of Abstraction

{shiny}

fluidRow()

{htmltools}

div(class="row", ...)

Raw HTML

<div class="row">...</div>

Empowers users across spectrum of design experience

Cascading Style Sheets (CSS)

Set of rules that define how HTML content is presented in the browser

selector {
  property1: value;
  property2: value;
}

• selector defines which elements on page to apply rule
• property list set properties of elements to specific values

Customizing CSS in Shiny (1)

ui <- fluidPage(
  tags$head(
    tags$style(
      HTML("
      body {
        background-color: blue;
        color: white;
      }")
    )
  ),
  # application UI
  ...
)

• tags originates from {htmltools}, but imported with {shiny}

Customizing CSS in Shiny (2)

# app.R

ui <- fluidPage(
  tags$head(
    tags$link(
      rel = "stylesheet",
      type = "text/css",
      href = "custom.css"
    )
  )
)

/* www/custom.css */

body {
  background-color: blue;
  color: white;
}

Customizing CSS in Shiny (3)

ui <- fluidPage(
  h2(
  "Art Viewer Application",
  style = "font-family: monospace;"
  ),
  ...
)

Code-Along

Streamline the design of {simclindata.shiny} with a pinch of customization
